The Hardware

ECA Technologies Africa supplies devices designed and developed for the synthesis of washing, disinfecting, sterilising and biologically active solutions. The applications for this technology are infinite and include any process requiring sterilisation, disinfecting or water purification.

ECA Tech Africa EL-3000

The environmental and ecological benefits from the significant reduction in chemical usage is one of the key benefits for using ECA Tech.

ECA Tech Africa EL-400

Africa units from water purification and agricultural industry through to all major industries with waste water and water processing problems.

Features of ECA Tech Africa Units

They have been developed to automatically produce activated solutions of different types and strengths to suite your needs. They perform as a standalone unit or can easily be implemented in a continuous process in more complex systems

A self cleaning cycle has been programmed into all machines which ensures easy maintenance, maximum productivity and long lifetime without maintanance.

ECA Tech Africa EL-1200

ECO-120

The unique design of the central cell ensures that electrolyte used to produce activated solutions has maximum contact with the electrodes and therefore ensures the most effective use of energy and minimum waste of raw materials.

There is a minimal hydraulic resistance against liquids flowing through the cell chambers which guarantees that optimum flow rate is achieved.

The electrodes are specifically designed to endure high electrochemical loading as are the membranes which separate the solutions.

The control system is simple and easy to operate. It can be altered to suit differing applications and conditions.

ECA Tech Africa ELA-900

ECA Tech Africa ELA-3000

Stabilisation of working current is introduced to ensure a stable quality of the generated solutions.

Brine feed ventures and pinch valves are introduced to ensure accurate dosage under all conditions at any time.

The enclosure is made of non-corrosive materials. Tubes and connectors are of EPDM/PVDF plastics and are highly resistant against aggressive solutions.

All input and output connectors are located either at the rear or at one side of the unit to enable easy installation.

ECA Tech Africa ELA-6000

ECA Tech Africa ELA-900

A simple on/off switch with power indicator starts and stops the unit manually.

Level-switches enable to start and stop the unit automatically.

Benefits of ECA Tech Africa Units

  • Connector.

    Easy and Safe to Use

  • Connector.

    Efficient: 1-5 minutes sterilisation contact time

  • Connector.

    Self cleaning

  • Connector.

    Cost effective

  • Connector.

    Fully automated

  • Connector.

    Fixed strength solutions

  • Connector.

    Simple installation and maintenance

  • Connector.

    Environmentally and ecologically friendly

  • Connector.

    No moveable or replaceable parts

ECA Tech Africa ELA-6000/
CMU-industrial

ELA-2000/CMU-industrial

The units electrolyze salt (brine solution) and water using polymer or ceramic membranes to separate the positive and negative ions. As a result of the chemical reactions two types of activated solutions are produced: Anolyte-strong and fast-acting disinfectant which kills all known bacteria and viruses within minutes and Catholyte – an alkaline solution which removes heavy metals from water through precipitation or serves as an excellent washing liquid.

ECA Tech Africa Seawater Unit

ECA Tech Africa Seawater Unit

The units are built in different sizes to address different applications. The units can be used either where only small volumes of disinfectants are required for domestic treatment or for large scale projects where disinfection, sterilisation or water purification are required. The strength of the solutions can be also varied by changing the electrical input into the units.

PC/Internet control is optional for all units. This allows remote monitoring of the unit to remedy any potential problem from a control room at any location or distance form the installation site.
